800 - 1250kg Home Shopping Center Passenger Elevator Lift Small Machine Room

800 - 1250kg Home Shopping Center Passenger Elevator Lift Small Machine Room
800 - 1250kg Home Shopping Center Passenger Elevator Lift Small Machine Room

Large Image :  800 - 1250kg Home Shopping Center Passenger Elevator Lift Small Machine Room

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Machine Roomless Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Machine Roomless Elevator Load: 800~1250kg
Speed: 1.0/1.75m/S Warranty: 1 Year
Transportation: Sea Delivery Product Name: Gearless Lift Motor For Elevator
Applicable: Residential Passenger Elevator Elevator Parts: Machine Roomless Elevator
Voltage: 380V/220V Material: Stainless Steel
Model: Machine Roomless Elevator
High Light:

Small Machine Room Home Elevator

,

Shopping Center Passenger Elevator

,

Passenger Elevator Lift 1250kg



Small Machine Room Spacious Home Shopping Center Passenger Elevator Lift




Rated Load Persons Drag Method Rated Speed Net Dimension of Car Dimension of Door Opening Dimension of Hoistway Over Head Pit Depth
Width Depth Width Height Width Depth
KG Num   m/s Unit:mm
800 10

V

V

V

F

1.0/1.75 1200 1600 800 2100 2050 2100 4800/5100 1800/2000
1000 13 1.0/1.75 1400 1800 900 2100 2250 2450 5000/5300 1800/2000
1250 16 1.0/1.75 1600 2000 900 2100 2500 2700 5000/5300 1800/2000






















800 - 1250kg Home Shopping Center Passenger Elevator Lift Small Machine Room 0

800 - 1250kg Home Shopping Center Passenger Elevator Lift Small Machine Room 1800 - 1250kg Home Shopping Center Passenger Elevator Lift Small Machine Room 2800 - 1250kg Home Shopping Center Passenger Elevator Lift Small Machine Room 3800 - 1250kg Home Shopping Center Passenger Elevator Lift Small Machine Room 4
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
