AC VVVF Mirror Etched Residential Dumbwaiter Elevator Electric


Large Image :  AC VVVF Mirror Etched Residential Dumbwaiter Elevator Electric

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Dumbwaiter Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $3000~7000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Dumbwaiter Elevator Load: 100~500kg
Drive Type: AC VVVF Speed: 1.0M/S
Material: Stainless Steel Usage: Dumbwaiter Elevator
Keywords: Dumbwaiter Car Wall: Mirror Etching Stainless Steel
High Light:

mirror etched dumbwaiter elevator


AC VVVF Dumbwaiter Elevator


mirror etched residential dumbwaiter

Hot Sale Service Library Restaurant Kitchen Food Elevator Lift


Dumb Waiter is normally installed in door for fast delivery of food. LIFT,The load capacity is normall 50-300kg, we can also customize it according to your need.
The structure part are all galvanized steel and cabin stainless steel type, the lift of whole structure is at least 10 years.


Load(KGS) Type Cabin Clear Size Shaft Clear Size Overhead Height Pit Depth Entrance Reserved Size Motor Power(KW)
    A(Width) B(Depth) C(Height) D(Width) E(Depth)     F G H
100 Window Type 750 750 900 1250 900 >=3600 - 750 1000 600 1.1
100 Trolley Type 750 750 900 1250 900 >=3600 600 750 1000 - 1.1
200 Window Type 900 900 1000 1400 1100 >=3600 - 900 1100 800 1.5
200 Trolley Type 900 900 1000 1400 1100 >=3600 800 900 1100 - 1.5
250 Window Type 950 950 1000 1450 1150 >=3600 - 950 1100 800 2.2
250 Trolley Type 950 950 1000 1450 1150 >=3600 800 950 1100 - 2.2
300 Trolley Type 1000 1000 1100 1500 1200 >=3600 1200 1000 1200 - 3
500 Trolley Type 1100 1100 1200 1600 1300 >=3600 1200 1100 1300 - 4


AC VVVF Mirror Etched Residential Dumbwaiter Elevator Electric 0


1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
