Product Details:
Payment & Shipping Terms:
|
| Certification: | ISO, CE Certificate | Name: | Machine Room Less Elevator |
|---|---|---|---|
| Load: | 450kg-1600kg | Speed: | 1.0m/s--2.5m/s |
| Persons: | 8-26 Person | Specification: | Standard |
| Usage: | Passenger Elevators | Elevator Door: | Center Opening Door |
| Transportation: | Sea Delivery | Voltage: | 380V/220V |
| Model: | Machine Room Less Elevator | Product: | Machine Room Less Elevator |
| High Light: | 2.5m/s Machine Room Less Elevator,DMPC Machine Room Less Elevator,2.5m/s lifts without machine room |
||
Promotional Commercial Machine-Room-Less Passenger Elevator Lift
MRL elevator utilizes a top-of-shaft machine and an under-slung car configuration. Coupled with the DMPC controller, the following performance standards can be achieved:
Speeds from 0.75 to 1.75 metres per second
Capacities from 910 to 2,050 kilograms
Travel up to 18 floors (50 metres)
Microprocessor-based dispatching and state-of-the-art VVVF AC motor control.
Safety features include infra-red door curtain, emergency cab lighting, emergency phone
Unlike other MRLs, the Delta MRL includes a rope gripper to prevent unintended motion.
Persons | Rated capacity (kg) | Rated speed (m/s) | Net size of car/CWxCDxDH | Net size of door DWxDH/2P Central opening | Shaft size/HWxHD |
6 | 450 | 1.0 | 1100x1100x2300 | 800x2100 | 2050x1850 |
8 | 630 | 1.0~1.75 | 1400x1100x2300 | 800x2100 | 2250x1900 |
10 | 800 | 1.0~2.5 | 1400x1350x2300 | 800x2100 | 2250x1950 |
13 | 1000 | 1.0~2.5 | 1500x1550x2300 | 900x2100 | 2350x2150 |
21 | 1600 | 1.0~2.5 | 1900x1800x2300 | 1100x2100 | 2850x2400 |
26 | 1600 | 1.0~2.0 | 1900x2200x2300 | 1100x2100 | 2900x2600 |
Machine roomless passenger elevator construction layout drawing.
FAQ
1. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
2. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
3. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
4. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
