Product Details:
Payment & Shipping Terms:
|
| Name: | Passenger Elevator | Speed: | 1.0 - 1.75m/s |
|---|---|---|---|
| Load: | 450-1600kg | Warranty: | 12 Months |
| Door Knife: | Single | Elevator Door: | Center Opening Door |
| Material: | Stainless Steel 304 | Control: | VVVF Elevator Control System |
| High Light: | Shopping Mall Safety Passenger Elevator,Stainless Steel 304 Passenger Elevator,ISO9001 Safety Passenger Elevator |
||
Speed 1.0 - 1.75m/S Safety Passenger Elevator For Commercial Shopping Mall And Office Building
The passenger elevator uses advanced electronics and an accurate and efficient control system. In addition, SUNNY lifts are manufactured using the latest environmental technologies, as well as safety devices and signaling devices. The SUNNY Passenger Elevator Series provides a safe ride.
Passenger Elevator Parameter
| Load capacity (Kg) |
Rated Speed m/s |
Car Size cw*cd(mm) |
Door Opening Size ew*eh(mm) |
Shaft Size hw*hd(mm) |
Top floor height Th(mm) |
Pit Depth (mm) |
| 450 | 1 | 1100×1100 | 800×2100 | 2050×1850 | 4500 | 1500 |
| 630 | 1 | 1400×1100 | 800×2100 | 2250×1900 | 4500 | 1500 |
| 1.5 | 4700 | 1600 | ||||
| 1.75 | ||||||
| 800 | 1 | 1400×1350 | 800×2100 | 2200×1950 | 4000 | 1500 |
| 1.5/ 1.75 |
4700 | 1600 | ||||
| 1000 | 1 | 1500×1550 | 900×2100 | 2350×2150 | 4000 | 1600 |
| 1.5/ 1.75 |
4700 | 1600 | ||||
| 1600 | 1 | 1800*2000 | 1100*2100 | 2900*2200 | 4350 | 1500 |
| 1.5/ 1.75 |
4500 | 1600 |
About Us
SUNNY Elevator is always engaged in researching into, developing, manufacturing various building traffic and transport systems such as elevator, escalator, moving walk etc. Through the centurial trials and hardships, SUNNY Elevator never changes its advanced technology.
SUNNY Elevators safely operate in all kinds of high grade buildings in over 100 countries and regions. As time flies, it continues the rigorous and conscientious spirits of the German nation. SUNNY Elevator popular-fixes the most superb elevators and escalators all aver the world and opens the gate of the artistic elevator palace.
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
Contact Person: Mr. Wei CHEN
Tel: +86-13661864321
