800kg 8 Persons Passenger Lift Elevator With Standard Design High Stability

800kg 8 Persons Passenger Lift Elevator With Standard Design High Stability
800kg 8 Persons Passenger Lift Elevator With Standard Design High Stability 800kg 8 Persons Passenger Lift Elevator With Standard Design High Stability

Large Image :  800kg 8 Persons Passenger Lift Elevator With Standard Design High Stability

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: 3C,CE
Model Number: Passenger elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Passenger Elevator Load: 630~1000kg
Warranty: 1 Year Type: Elevators
Product Name: Passenger Lift Control: VVVF Elevator Control System
Material: Stainless Steel 304 Traction Machine: Gearless Or Gear Machine
High Light:

small passenger lift

,

high speed elevator

630~1000kg 8 Persons Passenger Lift Elevator With Standard Design



SUNNY-Elevator.pdf

Advanced drive system

Armed with advanced gearless permanent magnet synchronous traction machine(PMSM),our elevators are famous for their simple structure, high speed and stability. They can reach maximum speed up to the world leading level, therefore, basically suiting building with different floors.





Load Person Speed Internal car size Internal car size Pit depth Overhead Power
kg no. m/s CWxCD(mm) SW(min) SD(min) SW(max) SD(max) (mm) (mm) (kw)
630 8 1.0 1400x1100x2400 1900 1800 2300 2200 ≥1500 ≥4500 4.5
1.5 ≥1600 ≥4600 6.8
1.75 ≥1700 ≥4600 7.9
800 10 1.0 1400x1350x2400 2000 2050 2400 2450 ≥1500 ≥4400 5.5
1.5 ≥1600 ≥4500 8.3
1.75 ≥1700 ≥4600 9.6
2.0 ≥1800 ≥4800 13.5
2.5 ≥2200 ≥5000 16.8
1000 13 1.0 1600x1400x2400 2100 2100 2500 2500 ≥1500 ≥4400 6.7
1.5 ≥1600 ≥4500 10
1.75 ≥1700 ≥4600 11.7
2 ≥1800 ≥4800 13.5
2.5 ≥2200 ≥5000 16.8



Which motor is used in elevator?
Lifts and elevators use asynchronous motors. The latest elevator designs use 3-phase induction motors with variable frequency drive electronic controls. Some may also use a similar system with permanent magnet (brushless) DC motors.



800kg 8 Persons Passenger Lift Elevator With Standard Design High Stability 0



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
