Large Space Hospital Elevator High Speed 1100*2100 Opening Door Size

Large Space Hospital Elevator High Speed 1100*2100 Opening Door Size
Large Space Hospital Elevator High Speed 1100*2100 Opening Door Size Large Space Hospital Elevator High Speed 1100*2100 Opening Door Size

Large Image :  Large Space Hospital Elevator High Speed 1100*2100 Opening Door Size

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Hospital Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000-12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Hospital Elevator Load: 1600kg
Speed: 1.0~1.75m/S Pit Depth: 1500mm
Opening Door Size: 1100*2100mm Size Of Car: 1400*2400*2250mm
Drive Type: AC Type: Hospital Elevator
Model: Hospital Elevator
High Light:

hospital bed lift

,

hospital lift

High Speed Elevator Large Space Stainless Steel For Hospital 1100*2100 Opening Door Size

Large Space Hospital Elevator High Speed 1100*2100 Opening Door Size


Hospital elevator
The inner wall of the lift car adopts the stainless steel overlapping uprights and the stainless steel skirting lines,which can be perfectly combined with the high-quality panel materials, thus further highlighting the stable and generous atmosphere.
Machine roomless hospital elevator parameter table


Load

(kg)

Speed

(m/s)

Size of entrance

(mm)

Size of car

(mm)

Size of hoistway

(mm)

Overhead height

(mm)

Pit depth

(mm)

Max travelling height(m)
1600 1.0

1100*2100

center-opening

1400*2400*2250 2400*2800 4100/4300 1500 30/50
1.6 4250/4400 1600 30/60
1.75 4300/4400 1650 30/75
1600 1.0

1300*2100

side-opening

1400*2400*2250 2400*2900 4200/4300 1500 30/50
1.6 4350/4400 1600 30/60
1.75 4400/4450 1650 30/75

1600

(Through door)

1.0

1100*2100

center-opening

1400*2400*2250 2400*2910 4100/4300 1500 30/50
1.6 4250/4400 1600 30/60
1.75 4300/4400 1650 30/75

1600

(Through door)

1.0

1300*2100

side-opening

1400*2400*2250 2400*3050 4200/4300 1500 30/50
1.6 4350/4400 1600 30/60
1.75 4400/4450 1650 30/75


Large Space Hospital Elevator High Speed 1100*2100 Opening Door Size 0
Large Space Hospital Elevator High Speed 1100*2100 Opening Door Size 1

 Large Space Hospital Elevator High Speed 1100*2100 Opening Door Size 2



Large Space Hospital Elevator High Speed 1100*2100 Opening Door Size 3Large Space Hospital Elevator High Speed 1100*2100 Opening Door Size 4Large Space Hospital Elevator High Speed 1100*2100 Opening Door Size 5



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
