Advanced Machine Room Elevator Portal Frame Household Lifts For Residential Home

Advanced Machine Room Elevator Portal Frame Household Lifts For Residential Home
Advanced Machine Room Elevator Portal Frame Household Lifts For Residential Home

Large Image :  Advanced Machine Room Elevator Portal Frame Household Lifts For Residential Home

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Home elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000-12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Residential Home Load: 250~400kg
Speed: 0.4m/s Open The Door Way: Double-folede Center Opening
Warranty: 1 Year Model: Residential Home
Drive Type: AC Material: Stainless Steel 304
Type: Residential Home
High Light:

modern home elevators

,

in home elevators and lifts

Home elevator / Portal frame house hold elevator / Advanced machine-room-less structure

Advanced Machine Room Elevator Portal Frame Household Lifts For Residential Home



Home elevator integrates mature lift technologies into artistic space design.Humanistic design can perfectly combine the elevator with home fumishing. Flexible configurations and various intelligent technologies makes household lift perform well in safety,nose,comfort and energy-efficiency. The home elevator shows strong market competitiveness.



Advanced machine-room-less structure
Excellent elevator performance,unique structure experience.
Small occupation area,low civil requirements,can meet the needs of different types of villa structure.



More convenient installation structure of the main machine
Main machine installation,eliminate reserved holed,simple installation,free to enjoy.



More stable gantry road structure
Gantry car frame with rod structure,double stable structures to make the car running more comfortable and steady.



Loading
capacity

(kg)

Rated
speed

(m/s)

Door opening
width(mm)
Door opening
width(mm)
Door opening
height(mm)
Car size(mm)
Width Depth Height
Hoistway size(mm)
Width Depth

Top floor
height

(mm)

Pit
depth

(mm)

maximum
number stops

Max.travelling
height

(mm)

250 0.4 Double-folede
center opening
700 2000 900 1000 2100 1650 1450 3500 1100 5 12
320 0.4 Double-folede
center opening
800

1100 1100

2100

1850 1500
400 0.4 Double-folede
center opening
800

1100 1300

2100

1850 1700



Advanced Machine Room Elevator Portal Frame Household Lifts For Residential Home 0

Advanced Machine Room Elevator Portal Frame Household Lifts For Residential Home 1



Advanced Machine Room Elevator Portal Frame Household Lifts For Residential Home 2



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
