Low Noice Hospital Elevator Safe And Stable Hospital Bed Elevator 1600kg

Low Noice Hospital Elevator Safe And Stable Hospital Bed Elevator 1600kg
Low Noice Hospital Elevator Safe And Stable Hospital Bed Elevator 1600kg Low Noice Hospital Elevator Safe And Stable Hospital Bed Elevator 1600kg

Large Image :  Low Noice Hospital Elevator Safe And Stable Hospital Bed Elevator 1600kg

Product Details:

Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Hospital Elevator

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: $7000-12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Hospital Elevator Load: 1600kg
Speed: 1~2.5m/s Warranty: 1 Year
Material: Stainless Steel Keywords: Hospital Elevator
Certification: ISO9001 Control: VVVF Elevator Control System
High Light:

hospital lift

,

hospital bed elevator

Safe And Stable High Speed Elevator / Low Noice Hospital Elevator

Warm Concern,a Beautiful Humanity World

SUNNY hospital elevators are not just used in delivering passengers. Because of its use particularity, it has special and strict requirements to the elevator use properties. SUNNY hospital elevator can accurately control the elevators' running speed. It brings about the smooth and comfortable travel.
SUNNY hospital elevator lays special importance upon the humane design. It fully optimizes the car structure. It satisfies the clients' use requirements to the greatest extent. It creates a peaceful and graceful space for vast passengers.

SUNNY hospital elevator satisfies the needs of emergency patients' delivery. It applies humanization design and is equipped with a full set of top equipments. It is smooth and comfortable in running.
Hospital Elevator

Ceiling: SN-CC-525 style stainless steel frame,
Acrylic top panel and lighting decoration
Ventilation: Axial fan
Car wall : Hairline stainless steel
Handrail: SN-CH-711
Floor: SN-CF-606

Standard



Load

DL(KG)

Speed

V(m/s)

Car Dimension Hositway Dimension

Max No.of

Stops

Max Travel

(m)

Min Span

Between Various

Floors

Power

KW

Distance of

Bracket

Guide Rail(mm)

CW(mm) CD(mm) OP(mm)

Min HW

(mm)

Min HD

(mm)

Min S

(mm)

Min K

(mm)

1600 1 1400 2400

1100

(center-

opening)

2500 2850 1500 4300 20 60 2.7 11 2000
1.5 1600 4400 24 72 16.4
1.75 1600 4500 30 90 19.2
2.0 1700 4700 30 90 22
2.5 2000 5100 38 150 27.5


Optional


Load

DL(KG)

Speed

V(m/s)

Car Dimension Hositway Dimension

Max No.of

Stops

Max Travel

(m)

Min Span

Between Various

Floors

Power

KW

Distance of

Bracket

Guide Rail(mm)

CW(mm) CD(mm) OP(mm)

Min HW

(mm)

Min HD

(mm)

Min S

(mm)

Min K

(mm)

1600 1 1400 2400

1200

(side-

opening)

2400 2850 1500 4300 20 60 2.7 11 2000
1.5 1600 4400 24 72 16.4
1.75 1600 4500 30 90 19.2
2.0 1700 4700 30 90 22
2.5 2000 5100 38 150 27.5


Note: Reference only, for detail information, please contact SUNNY elevator.
Optional





hospital elevator
















































































































Low Noice Hospital Elevator Safe And Stable Hospital Bed Elevator 1600kg 2



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
