380V Load 2000kg 2.5m/S Vvvf Driving Machine Room Lift Stainless Steel

380V Load 2000kg 2.5m/S Vvvf Driving Machine Room Lift Stainless Steel
380V Load 2000kg 2.5m/S Vvvf Driving Machine Room Lift Stainless Steel

Large Image :  380V Load 2000kg 2.5m/S Vvvf Driving Machine Room Lift Stainless Steel

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: Passenger Elevator
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/ Year
Detailed Product Description
Name: Passenger Elevator Load: 320~2000kg
Speed: 1.0~2.5m/s Drive: Vvvf Driving System
Power Supply: 3 Phase, 380V, 50Hz Warranty: 12 Months After Shipping
Usage: Freight Elevator Material: Stainless Steel
High Light:

Vvvf Driving Machine Room Lift

,

2.5m/S Machine Room Lift

,

Load 2000kg Machine Room Lift

Load 320~2000kg Passenger Elevator with Machine Room From China Manufacturer



MACHINE ROOM

Capacity Rated speed Power Controlledway Car size Open door size Hoistway size
kg m/s kw C.W C.D H D.W D.H H.W H.D P.H HR.H
320 1.0 2.2 VVVF 1100 850 2500 700 2100 1600 1450 1450 4200
1.5 2.9 1600 4350
1.75 3.4 1650 4400
450 1.0 3.0 1100 1100 2500 800 2100 1800 1700 1450 4200
1.5 4.3 1600 4350
1.75 5.0 1650 4400
630 1.0 4.0 1400 1100 2500 800 2100 2000 1700 1450 4200
1.5 6.0 1600 4350
1.75 7.0 1650 4400
800 1.0 5.0 1400 1350 2500 800 2100 2000 2000 1450 4200
1.5 7.8 1600 4350
1.75 9.0 1650 4400
2.0 11.0 1750 4600
2.50 13.5 2000 4900
1000 1.0 6.4 1600 1500 2500 900 2100 2150 2200 1450 4200
1.5 9.0 1600 4350
1.75 11.0 1650 4400
2.0 13.5 1750 4600
2.50 17.0 2000 4900
1150 1.0 7.5 1800 1500 2500 1100 2100 2400 2200 1450 4200
1.5 11.5 1600 4350
1.75 13.0 1650 4400
2.0 15.0 1750 4600
2.50 18.5 2000 4900
1250 1.0 9.0 1800 1550 2500 1100 2100 2400 2250 1450 4300
1.5 15.0 1600 4450
1.75 15.0 1650 4500
2.0 17.0 1750 4600
2.50 21.5 2000 4900
1350 1.0 9.0 1900 1600 2500 1100 2100 2500 2300 1450 4300
1.5 15.0 1600 4450
1.75 15.0 1650 4500
2.0 17.0 1750 4600
2.50 21.5 2000 4900
1600 1.0 10.0 2000 1750 2500 1100 2100 2600 2450 1450 4300
1.5 18.0 1600 4450
1.75 18.0 1650 4500
2.0 21.0 1750 4600
2.50 26.0 2000 4900
1800 1.0 12.5 2200 1700 2500 1100 2100 2800 2400 1450 4300
1.5 19.8 1600 4450
1.75 21.7 1650 4500
2.0 24.8 1750 4600
2.50 31.0 2000 4900
2000 1.0 13.0 2400 1700 2500 1100 2100 3000 2400 1450 4300
1.5 18.0 1600 4450
1.75 22.0 1650 4500
2.0 27.0 1750 4600
2.50 34.0 2000 4900



380V Load 2000kg 2.5m/S Vvvf Driving Machine Room Lift Stainless Steel 0



380V Load 2000kg 2.5m/S Vvvf Driving Machine Room Lift Stainless Steel 1



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
